Architectural Drawing

From building a new house to adding an extension, porch, or dormer, we’ll turn your Ideas into a complete set of drawings with all the documentation needed for planning approval.



To arrange a no-obligation quotation, just give ·      Call Paul or Graham for a free quote.

 ·      Most extensions can be priced over the phone, with no hidden fees.

 ·      Once you’re ready, we’ll visit to measure up and discuss your design.

 ·      We’ll advise on building work, groundworks, drains, and more.

 ·      Most extensions, lofts, and dormers are usually completed within two weeks.

 ·      You will receive draughts of the drawings so you can advice on any changes to the drawings prior to us applying for planning permission.

 ·      Option of 3D Models if required


Services

  • Full Architectural Drawings for.
  • Planning Application.
  • Extensions, porches, Dormers, Garages.
  • All Commercial and HMOs.
  • Building regulations.
  • Structural calculations
  • Building work estimation.
  • 3D Model drawings as an Option.


                     Free Services

We deal with all the planning process on your behalf. sending all documentation and drawings to your local council, Planning department.

Your tradesmen are welcome to contact us at any point with questions concerning the Prodject.

            Calculations                             Building a new project

Most building projects require some structural calculations. We provide these calculations

for all our drawings, whether it’s for a single RSJ support or a full extension.


Most timber work, including roofs, floors, walls, staircases, and fire-rated joinery,

requires regulations or calculations to be clearly shown on detailed drawings.

 Structural Calculations self-Building Projects.

We supply structural calculations for small building companies.

Steel Beam Calculations, Ridge beams, Loft floor Beams, All timber calculations.


For this type of calculation, a full set of drawings with photo images are required, or a site visit.



Rear Extension

Single Storey Extension

Plans Included.

Demolition of existing conservatory.

Ploor plans.

Elevation Plans.

Complete set of Working drawings.

Building regulations.

Engineers' calculations for two RSJ Supports.


Garden Office

Home Garden Extension, Office with Toilet.


Garden Office built using same method as building an extension.

This Build required planning Permission.

Cellar Conversion plan

Plans for converting the cellar into a living space included meeting drainage regulations. Drainage from the higher external ground was designed to be removed using a concealed pump, and all walls were tanked to prevent any dampness.

The Plan consisted of two rooms. living/ bedroom.

Bathroom.

Side Extension.

New First Floor, With Converted existing garage
